KALIPER® 360 (K360)

kaliper-360

Detection Capabilities

Construction Anomalies
  • Dents
  • Wrinkles
  • Flat spots

Designed for both new construction and in-service pipelines, KALIPER® 360 Technology makes the pipeline bore validation process faster and more cost-effective. Accurate detection of anomalies, locations and severity is coupled with quick reporting.

Key Features

  • Flexible enough to pass bore restrictions up to 30% of nominal pipe diameter
  • Lightweight design produces minimal drag; fewer air compressors needed to propel the tool
  • Reliable performance in different pipe wall thicknesses and piping/valve/bend configurations
  • Detection and sizing for dents 2% nominal pipe OD and greater
  • Accuracy of +/- 2% deformation

Sizes

  • 16-inch through 48-inch

Designed for both new construction and in-service pipelines, KALIPER® 360 Technology makes the pipeline bore validation process faster and more cost-effective. Accurate detection of anomalies, locations and severity is coupled with quick reporting.

Detection Capabilities

Construction Anomalies
  • Dents
  • Wrinkles
  • Flat spots

Key Features

  • Flexible enough to pass bore restrictions up to 30% of nominal pipe diameter
  • Lightweight design produces minimal drag; fewer air compressors needed to propel the tool
  • Reliable performance in different pipe wall thicknesses and piping/valve/bend configurations
  • Detection and sizing for dents 2% nominal pipe OD and greater
  • Accuracy of +/- 2% deformation

Sizes

  • 16-inch through 48-inch
